ROQdry RUN
ROQdry RUN, is a flash cure unit that can answer to any need that a printer can have. After exploring, experimenting and evolving the technology of the flash units ROQ decided to create the ROQdry RUN. A powerful and versatile platform it is a construction optimized for performance.
Description
Description du Produit
- Analogic control panel;
- 3 selectable drying areas;
- Controlable temperature;
- Heat transmission by convection and radiation;
- Suitable for larger drying areas;
- Test function;
- Several power options available;
Caractéristiques
| ROQ DRY RUN | 3000 S | 9000 M | 14400 XL | 18000 XL+ | 20400 2XL | 25500 3XL |
|---|---|---|---|---|---|---|
| Lenght (mm/feet) A | 1291 / 4.24” | |||||
| Height (mm/feet) B | 1220 / 4.00” | |||||
| Width (mm/feet) C | 625 / 2.05” | |||||
| Drying area (mm/inch) D x F | 200×200 / 8”x8” | 400×500 / 16”x20” | 500×700 / 20”x28” | 600×800 / 24”x28” | 700×1000 / 28”x39” | 800×1100 / 21”x43” |
| Hood size (mm/inch) | 615×786 / 24.2”x30.9” | |||||
| Power supply (VAC) | 1×230|3×230|3×400 | |||||
| Max. Consumption (kVA) | 3 | 9 | 14.4 | 18 | 20.4 | 25.5 |
| Power/area (W/cm²) | 7.14 | 5 | 4.11 | 3.7 | 2.91 | 2.89 |
| Lamps | 6x500W | 9x1000W | 12x12000W | 15x1200W | 24x850W | 30x850W |
| Plug (32A or 63A) | 32 (400V) | 32 (400V) | 63 (230V) | ||||
